Yaesu GX1300E收發器
原裝行貨 一年保用
- Affordable Ultra Compact Fixed Mount VHF Radio
- Meets ITU-R M.493-13 Class D DSDC
- Built in Seperate DSC Receiver for CH 70
- Easy to Operate icon driven Menu system
- Oversized Full Dot Matrix display 31mm x 55mm
- DSC Distress, Individual, Group, All Ships, Postion Request, Position Report, and DSC Test Call
- GPS position and Times shown on Display when connected to a GPS Reciver
- NMEA0183 input and output connecitons to a compatible NMEA device
- User programmable soft keys for menu selection
- Sumbersible to IPX-8 ( 1.5M for 30 minutes)
- All international, USA and Canadian Marine Channels.
- Preset key used to recall upto 1o favourite channels.
- Prgrammable Scan, Priority Scan,and Multi ( Dual or Triple) watch
- ATIS mode for European Inland Waterways
Specifications
GX1300E / Eclipse
General
Channels
All USA, International and Canadian
Input Voltage
13.8 VDC +-20%
Current Drain
Standby
0.3A
Receiver (Max AF Output)
1.0A
Transmit
5.5A (Hi), 1.5A (Lo)
Distress Call Log
26
Individual Call Log
64
Individual Call Directory
80
Group Call Directory
32
Waypoing Directory
100
Dimensions (W x H x D, mm)
155 x 60 x 150
Flush Mount Dimensions (W x H x D, mm)
131 x 51 x 140
Weight (approx)
870g
TRANSMITTER
Frequency Range
156.025 to 157.425 MHz
RF Output Power
25W (Hi), 1W (Lo)
Conducted Spurious Emissions
Less than -80dBc (Hi), -66dBc (Lo)
Audio Response
within +1/-3dB of a 6db Octave
pre-emphasis characteristic at 300 to 3000Hz
Audio Distortion
less than 5%
Modulation
16K0G3E (for Voice), 16K0G2B (for DSC)
Frequency Stability
±3ppm (-20ºC to +60ºC)
FM Hum and Noise
50dB
RECEIVER (For Voice and DSC)
Frequency Range
156.050 to 162.000MHz
Sensitivity
12dB SINAD
0.25µV
Modulation Acceptance Bandwidth
±7.5kHz
Selectivity (Typical)
Spurious and Image Rejection
75dB
Intermodulation and Rejection
70dB
Audio Output
4.5W (@ 4Ω external speaker output)
Frequency Stability
±3ppm (-20ºC to +60ºC)
Channel Spacing
25kHz
DSC Format
ITU-R M.493-13
NMEA Input/Output
NMEA 0183 GPS Input (4800 baud) for posn data
GSA, GSV, GGA, GLL, GNS, RMC
NMEA 0183 DSC Output (4800 baud)
DSC and DSE
